| Rod D1Ø | 6MM | 0.24" | |
|---|---|---|---|
| Cylinder D2Ø | 19MM | 0.75" |
| Stroke lengths (S): | 10-210MM | 0.39" - 8.27" | |
|---|---|---|---|
| Extended length EL1: | Stroke (S)*2 +30MM | 1.18" | shortest possible |
| Extended length EL2: | Stroke (S)*2 +30MM | + connecting parts |
| Force (F1) range: | 10-400N | 2.25-90Lbs |
|---|
| Rod: | QPQ | ||
|---|---|---|---|
| Cylinder: | Black |
| Damping: | Normal/No/Increased | ||
|---|---|---|---|
| Speed: | Normal/Slow/Fast | ||
| Working temperature: | -30°C +80°C | -22°F +176°F | |
| Progression ( approx.): | 17% |
| Part # 302 | Threaded ends M6x1.00 | ||
|---|---|---|---|
|
|
L: 6MM | 0.236" |
| Extended length (EL): Stroke (S)*2 +30MM/1.18" ( shortest possible ) |
| Part # 312 | Eye ends E6 | ||
|---|---|---|---|
|
|
A: M6x1.00 B: Ø6.1MM C: 11MM D: 16MM E: 3MM |
0.24" 0.43" 0.63" 0.12" |
| Extended length (EL2): Stroke (S)*2 +62MM/2.44" ( shortest possible ) |
| Part # 312.2 | Eye ends E6.1 | ||
|---|---|---|---|
|
|
|
A: M6x1.00 B: Ø6.1MM C: 11MM D: 16MM E: 6MM |
0.24" 0.43" 0.63" 0.236" |
| Extended length (EL2): Stroke (S)*2 +62MM/2.44" ( shortest possible ) |
| Part # 322 | Clevis ends C6 | ||
|---|---|---|---|
|
|
d2: M6x1.00 d1: Ø6MM B: 6MM G: 12MM L1: 31MM L2: 24MM |
0.236" 0.236" 0.47" 1.22" 0.94" |
| Extended length (EL2): Stroke (S)*2+78MM/3.07" ( shortest possible ) |
| Part # 332 | Angle ball joint ends A6 | ||
|---|---|---|---|
|
|
d2: M6x1.00 d2/1: M6x1.00 a: 25MM d1: ball Ø10MM L2: 16.5MM |
0.98" 0.49" |
| Extended length (EL2): Stroke (S)*2+80MM/3.15" ( shortest possible ) |
| Part # 332.3 | Angle ball joint ends A6.3 | ||
|---|---|---|---|
|
|
|
d2: M6x1.00 d2/1 5/16-18UNC a: 25MM d1: ball Ø10MM L2: 16.5MM |
0.98" 0.65" |
| Extended length (EL2): Stroke (S)*2+80MM/3.15" ( shortest possible ) |
| Part # 332.5 | Angle ball joint ends A6.5 | ||
|---|---|---|---|
|
|
|
d2: M6x1.00 d2/1 M8x1.25 a: 25MM d1: ball Ø10MM L2: 16.5MM |
0.98" 0.65" |
| Extended length (EL2): Stroke (S)*2+80MM/3.15" ( shortest possible ) |
| Part # 342 | Nylon ball socket ends P6 | ||
|---|---|---|---|
|
|
d2: M6x1.00 a: 18MM d1: ball Ø10MM |
0.71" |
| Extended length (EL2): Stroke(S)*2+66MM/2.60" ( shortest possible ) |
| Part # 342.3 | Nylon ball joint ends P15 | ||
|---|---|---|---|
|
|
d2: M6x1.00 d2/1: 5/16-18UNC a: 18MM d1: ball Ø10MM L2: 16.5MM |
0.71" 0.65" |
| Extended length (EL2): Stroke(S)*2+66MM/2.60" ( shortest possible ) |
| Part # 342.4 | Nylon ball joint ends P16 | ||
|---|---|---|---|
|
|
|
d2: M6x1.00 d2/1: M8x1.25 a: 18MM d1: ball Ø10MM L2: 16.5MM |
0.71" 0.65" |
| Extended length (EL2): Stroke(S)*2+66MM/2.60" ( shortest possible ) |
| Part # 362 | Metal ball socket ends B30 | ||
|---|---|---|---|
|
|
d2: M6x1.00 a: 25MM d1: ball Ø10MM |
0.98" 0.71" |
| Extended length (EL2): Stroke(S)*2+80MM/3.15" ( shortest possible ) |
| Part # 367 | Rod end bearings RB6 | ||
|---|---|---|---|
|
|
d3: M6x1.00 L1: 30MM d1: Ø6MM L2: 20MM |
1.18" 0.24" 0.787" |
| Extended length (EL2): Stroke(S)*2+90MM/3.45" ( shortest possible ) |
Options: |
|||
|---|---|---|---|
| - Reducible force: | V |  |
|
| - Friction: | F |  |
EL1/EL2 10MM longer |
| - Dust boot: | D |  |
|
| - Rod protector: | R |  |
Stroke reduction 5MM |
| - Horizontal use: | H |  |
EL1/EL2 increase |
| - Low temperature -45°C / -49°F | A | ||
| - High temperature 200°C / 392°F | B | ||
| - No end fittings: |  |
||
| - Extended thread length: |  |
||
| - Cylinder end with groove: |  |
||
| - Private label | P |
|
|
|||
| Product Inquiry example: | |||
| Part # | Stroke (S) MM/INCH | Length (EL2) MM/INCH | Force N/Lbs | Damping | Speed | Working temp | Options |
|---|---|---|---|---|---|---|---|
| 312 | 100 / 3.94 | 254 / 10.00 | 180N/40Lbs | Normal | Normal | Normal |
| Extended length (EL) of a gas compression spring is calculated when piston rod is fully extended |
| Force (F1) measured with piston rod 5MM/ 0.20" compressed |
| Progression rate will change depending on cylinder volume |
| Connecting parts are interchangeable, make your own combination or go to product category connecting parts to view more options |
| Please be advised that Extended Length EL2 will change depending on your choice of connecting parts |
