| Rod D1Ø | 10MM | 0.39" | |
|---|---|---|---|
| Cylinder D2Ø | 28MM | 1.10" |
| Stroke lengths (S): | 20-800MM | 0.79"-31.50" | |
|---|---|---|---|
| Extended length EL1: | Stroke (S)*2 + 77MM / 3.03" | (shortest possible) | |
| Extended length EL2: | Stroke (S)*2 + 77MM / 3.03" | + cylinder end fitting |
| Force (F1) range: | 50-1300N | 11.25-292Lbs |
|---|
| Rod: | QPQ | ||
|---|---|---|---|
| Cylinder: | Black |
| Speed: | Normal/Slow/Fast | ||
|---|---|---|---|
| Working temperature: | -30°C +80°C | -22°F +176°F | |
| Progression ( approx.): | 25% |
| Part # 1608 | Cylinder thread M10x1.50 or M8x1.25 | ||
|---|---|---|---|
|
|
M10x1.50 L: 11MM M8x1.25 L: 9MM |
0.43" 0.35" |
| Extended Length (EL1/EL2): Stroke (S)*2 + 77MM/3.03" ( shortest possible ) |
| Part # 1618 | Eye ends E10 | ||
|---|---|---|---|
|
|
A: M10x1.50 B: Ø8.1MM C: 19MM D: 25MM E: 12MM |
0.319" 0.75" 0.98" 0.47" |
| Extended Length (EL2): Stroke (S)*2 + 102MM/4.02" ( shortest possible ) |
| Part # 1618.1 | Eye ends E8 | ||
|---|---|---|---|
|
|
|
A: M8x1.25 B: Ø8.1MM C: 16MM D: 20MM E: 10MM |
0.319" 0.63" 0.79" 0.39" |
| Extended Length (EL2): Stroke (S)*2 + 97MM/3.82" ( shortest possible ) |
| Part # 1618.5 | Fixed eye end E28.0808 | ||
|---|---|---|---|
|
|
|
B: Ø8.1MM C: 19MM D: 15MM E: 8MM |
0.319" 0.75" 0.59" 0.315" |
| Extended Length (EL2): Stroke (S)*2 + 92MM/3.62" ( shortest possible ) |
| Part # 1618.6 | Fixed eye end E28.0810 | ||
|---|---|---|---|
|
|
|
B: Ø8.1MM C: 19MM D: 15MM E: 10MM |
0.319" 0.75" 0.59" 0.39" |
| Extended Length (EL2): Stroke (S)*2 + 92MM/3.62" ( shortest possible ) |
| Part # 1618.7 | Fixed eye end E28.0812 | ||
|---|---|---|---|
|
|
|
B: Ø8.1MM C: 19MM D: 15MM E: 12MM |
0.319" 0.75" 0.59" 0.39" |
| Extended Length (EL2): Stroke (S)*2 + 92MM/3.62" ( shortest possible ) |
| Part # 1618.8 | Fixed eye E28.1010 | ||
|---|---|---|---|
|
|
|
B: Ø10.2MM C: 19MM D: 15MM E: 10MM |
0.40" 0.75" 0.59" 0.39" |
| Extended Length (EL2): Stroke (S)*2 + 92MM/3.62" ( shortest possible ) |
| Part # 1628 | Clevis end C10 | ||
|---|---|---|---|
|
|
d2: M10x1.50 d1: Ø10MM B: 10MM G: 20MM L1: 52MM L2: 40MM |
0.39" 0.39" 0.79" 20.05" 1.58" |
| Extended Length (EL2): Stroke (S)*2 + 117MM/4.61" ( shortest possible ) |
| Part # 1638 | Angle ball joint A10 | ||
|---|---|---|---|
|
|
d2: M10x1.50 d2/1: M10x1.50 A: 35MM d1: ball Ø16MM L2: 20MM |
1.38" 0.79" |
| Extended Length (EL2): Stroke (S)*2 + 112MM/4.41" ( shortest possible ) |
Options: |
|||
|---|---|---|---|
| - Valve: | V |  |
|
| - Rod protector: | R |  |
Stroke reduction 5MM |
| - Low temperature -45°C / -49°F | A | ||
| - High temperature 200°C / 392°F | B | ||
| - Extended thread length: |  |
||
| - Cylinder end with groove: |  |
||
| - Private label | P |
|
|
|||
| Product Inquiry example: | |||
| Part # | Stroke (S) MM/INCH | Length (EL2) MM/INCH | Force N/Lbs | Speed | Working temp | Options |
|---|---|---|---|---|---|---|
| 1618.6 | 250 / 9.84 | 592 / 23.31 | 300N / 68Lbs | Normal | Normal |
| Extended length (EL2) of a lockable gas compression spring is measured with rod fully extended and will change depending on type of actuator head. See category release systems for more information. |
| Thread piston rod: MF10x1x19MM. |
| Force (F1) measured with piston rod 5MM/ 0.20" compressed. |
| Progression rate will change depending on cylinder volume. |
| Connecting parts are interchangeable, go to product category connecting parts to view more options. |
| Please be adivsed that Extended Length EL2 will change depending on your choice of connecting parts. |
