Oil Damper Springs

Oil Dampers

Gas Compression Springs 6 19
Rod D1Ø6MM0.24"
Cylinder D2Ø19MM0.75"

Stroke lengths (S) :10-210MM0.39"-8.27"
Extended length EL1:Stroke (S)*2 +35MM1.38"( shortest possible)
Extended length EL2:Stroke (S)*2 +35MM+ connecting parts

Rod:QPQ
Cylinder:Black

Damping direction:CompressionCode: ODC
ExtensionCode: ODE
BothCode: ODB

Damping:Normal/Medium/Strong

Damping force:Max. 400N/90Lbs

Speed:Normal/Slow/Fast

Working temperature:-30°C +80°C-22°F +176°F

Part # 302OD_ (C/E/B)Threaded ends M6x1.00
Part # 3020D_ (C/E/B)Part # 3020D_ (C/E/B) threaded endsL: 6MM0.236"
Extended length (EL): Stroke (S)*2 +35MM/1.38" ( shortest possible )

Part # 312_ (C/E/B)Eye ends E6
Part # 312_ (C/E/B)Part # 312_ (C/E/B) eye ends A: M6x1.00
B: Ø6.1MM
C: 11MM
D: 16MM
E: 3MM

0.24"
0.43"
0.63"
0.12"
Extended length (EL2): Stroke (S)*2 +67MM/2.64" ( shortest possible )

Part # 312.2_ (C/E/B)Eye ends E6.1
Part # 312.2_ (C/E/B)Part # 312.2_ (C/E/B) eye ends A: M6x1.00
B: Ø6.1MM
C: 11MM
D: 16MM
E: 6MM

0.24"
0.43"
0.63"
0.236"
Extended length (EL2): Stroke (S)*2 +67MM/2.64" ( shortest possible )

Part # 322_ (C/E/B)Clevis ends C6
Part # 322_ (C/E/B)Part # 322_ (C/E/B) clevis ends d2: M6x1.00
d1: Ø6MM
B: 6MM
G: 12MM
L1: 31MM
L2: 24MM

0.236"
0.236"
0.47"
1.22"
0.94"
Extended length (EL2): Stroke (S)*2 +83MM/3.27" ( shortest possible )

Part # 332_ (C/E/B)Angle ball joint ends A6
Part # 332_ (C/E/B)Part # 332_ (C/E/B) angle ball joint ends d2: M6x1.00
d2/1: M6x1.00
a: 25MM
d1: ball Ø10MM
L2: 16.5MM


0.98"

0.49"
Extended length (EL2): Stroke (S)*2 +85MM/3.35" ( shortest possible )

Part # 332.3_ (C/E/B)Angle ball joint ends A6.3
Part # 332.3_ (C/E/B)Part # 332.3_ (C/E/B) angle ball joint ends d2: M6x1.00
d2/1 5/16-18UNC
a: 25MM
d1: ball Ø10MM
L2: 16.5MM


0.98"

0.65"
Extended length (EL2): Stroke (S)*2 +85MM/3.35" ( shortest possible )

Part # 332.5_ (C/E/B)Angle ball joint ends A6.5
Part # 332.5_ (C/E/B)Part # 332.5_ (C/E/B) angle ball joint ends d2: M6x1.00
d2/1 M8x1.25
a: 25MM
d1: ball Ø10MM
L2: 16.5MM


0.98"

0.65"
Extended length (EL2): Stroke (S)*2 +85MM/3.35" ( shortest possible )

Part # 342_ (C/E/B)Nylon ball socket ends P6
Part # 342_ (C/E/B)Part # 342_ (C/E/B) nylon ball socket ends d2: M6x1.00
a: 18MM
d1: ball Ø10MM

0.71"
Extended length (EL2): Stroke (S)*2 +71MM/2.80" ( shortest possible )

Part # 342.3_ (C/E/B)Nylon ball joint ends P15
Part # 342.3_ (C/E/B)Part # 342.3_ (C/E/B) nylon ball joint ends d2: M6x1.00
d2/1: 5/16-18UNC
a: 18MM
d1: ball Ø10MM
L2: 16.5MM


0.71"

0.65"
Extended length (EL2): Stroke (S)*2 +71MM/2.80" ( shortest possible )

Part # 342.4_ (C/E/B)Nylon ball joint ends P16
Part # 342.4_ (C/E/B)Part # 342.4_ (C/E/B) nylon ball joint ends d2: M6x1.00
d2/1: M8x1.25
a: 18MM
d1: ball Ø10MM
L2: 16.5MM


0.71"

0.65"
Extended length (EL2): Stroke (S)*2 +71MM/2.80" ( shortest possible )

Part # 362_ (C/E/B)Metal ball socket ends B30
Part # 362_ (C/E/B)Part # 362_ (C/E/B) metal ball socket ends d2: M6x1.00
a: 25MM
d1: ball Ø10MM

0.98"
0.71"
Extended length (EL2): Stroke (S)*2 +85MM/3.35" ( shortest possible )

Part # 367_ (C/E/B)Rod end bearings RB6
Part # 367_ (C/E/B)Part # 367_ (C/E/B) rod end bearings d3: M6x1.00
L1: 30MM
d1: Ø6MM
L2: 20MM

1.18"
0.24"
0.787"
Extended length (EL2): Stroke (S)*2 +95MM/3.74" ( shortest possible )

Options:

- Dust boot:
D
Option dust boot
- Rod protector:
R
Option rod protector
Stroke reduction 5MM
- Lockable protector:
L
Option lockable protector
Stroke reduction 5MM
- Horizontal use:
H
Option horizontal use
EL1/EL2 increase
- Low temperature -45°C / -49°F
A
- High temperature 200°C / 392°F
B
- No end fittings:
Option no end fittings
- Extended thread length:
Option extended thread length
- Cylinder end with groove:
Option cylinder end with groove
- Private label
P

Product Inquiry example:
Part #Stroke (S) MM/INCHLength (EL2) MM/INCHWeight of objectDampingSpeedWorking tempOptions
312ODE100 / 3.94254 / 10.00--NormalNormalNormal
Extended length (EL) of an oil damper is calculated when piston rod is fully extended
Connecting parts are interchangeable, make your own combination or go to product category connecting parts to view more options
Please be advised that Extended Length EL2 will change depending on your choice of connecting parts
